Technical Details

• Scan Mode: Fixed Scan with Turntable, Fixed Scan without Turntable
• Align Mode: Manually Align; Feature Align; Turntable Align; Markers Align; Turntable Coded Target Align
• Scan Accuracy:  ≤0.05mm
• Minimum Scan Volume:  30mm × 30mm × 30mm
• Maximum Scan Volume: Fixed Scan: 1200mm × 1200mm × 1200mm Turntable: 200mm × 200mm × 200mm
• Singe Scan Range:  200 mm × 150 mm
• Scan speed of a single shot:  ＜1s
• Scan speed of one turn:  ＜45s
• Point Distance:  0.17mm ~ 0.2mm
• Color Scan:  Supported
• Output Formats: OBJ, STL, ASC, PLY, 3MF
• Camera Resolution:  1.3MP
• Light Source: White LED
• Working Distance: 290mm ~ 480mm
• Power Supply: 12V, 3.33A, 40W
• Computer Requirements: OS: Win7, 8, 10 (64bit), CPU: Intel Dual Core i5 or higher,RAM: ＞16GB, Graphics Card: Nvidia GTX660 or higher, Video Memory: ＞2GB, USB Port: 2.0/ 3.0
• Device Size:  570mm × 210mm × 210mm
• Package Size:  640mm × 410mm × 230mm
• Weight: 4.2KG
• Certificate: BIS, CE, FCC, ROHS, WEEE
• Calibration Board: Plastic Calibration Board
• Turntable Loading Capacity: 5KG
• Attachments: Tripods, Software for Solid Edge SHINING 3D Edition
